Vertex 222

VERTEX 222

Complete Room Coverage Decontamination

The Vertex 222 is a state-of-the-art sanitation solution for optimal room coverage. With its 222 nm Krypton Chloride Excimer Lamp, this versatile device can be installed in corners, ensuring comprehensive decontamination.

Category: Tags: ,

Description

Complete Room Coverage Decontamination with Vertex 222

The Vertex 222 model is designed to be either fixed or portable, making it easy to position in key locations within the desired area. The lamps utilise strategically positioned light sources to ensure uniform distribution of decontaminating Far-UVC light. Used independently in corner locations or in combination with other UV222 solutions from UV Medico, the Vertex 222 provides a comprehensive approach to creating safer and healthier environments.

Whether you choose a fixed or portable model, Vertex 222 offers programmable modes and robust construction, ideal for various environments seeking a safer, cleaner space.

Key Features:

  • Optimal Wavelength: Utilises 222 nm light for effective sanitisation.
  • Flexible Installation: Designed for corners, maximising room coverage.
  • Customisable Operation: Features continuous, duty cycle, and motion-sensor modes.
  • Durable and Efficient: IP65 rated with minimal power consumption.



Far UVC lamp certification logos



Specifications

Light source Krypton chloride excimer lamp
Wavelength 222 nm
Output 460 mW (Typical)
Dose in 15 sec. (on sole) 15 mJ/cm² †
Input voltage 90-264 V AC
Mode (programmable) Continuous / duty cycle/motion sensor
Max power consumption 120 W
Dimensions 167 x 136.5 x 530 mm (6.57 x 5.37 x 20.86 in)
Operating temperature 0° to + 40° C (32° to 104° F)
Ambient humidity 5-90% RH Non condensing
Materials Aluminum, quartz glass
Power Lead (PVC) 3 x 0.75 mm² (18 AWG)
Weight 4.5 kg (9.92 lbs)
